SPW-H CORE PUR

A wall sandwich panel with concealed locking and a CORE PUR core - made from polyurethane foam, which has excellent thermal insulation properties and mechanical strength. Joining the panels together is done using stress spreaders, gaskets, foil and self-drilling screws. The panel is available in a wide range of profiles, heat transfer coefficients and corrosion resistance options. On request, it can be made with special coatings: PVDF, PUR, PVC (P) and PVC (F) - FoodSafe.

ASK FOR A QUOTE CONTACT YOUR ADVISOR

Ask for product

BIM Library

The following product can be found in the BP2 BIM library for architects and designers.

Are you working on a roof design and looking for the best solution that would meet all your requirements? Let us provide you with BP2 Libraries to design using BIM modelling. Thanks to precise models, you will be able to prepare a complete 3D detailed design much faster and way easier.

Go to BIM Library

Technical information

Board cross-section

Joining of panels

Technical specifications

Core	PUR
Density [kg/m³]	40 ± 3
PUR panel thickness [mm]	60	80	100	120
Weight [kg/m²]	9,5	10,3	11,1	11,9
Effective width [mm]	1050
Total width [mm]	1102
Min. panel length [m]	2,0
Max. panel length [m]	15,0
Outer/inner sheet thickness [mm]	0,3-0,7 / 0,3-0,7
U-value [W/m²K]	0,37	0,28	0,22	0,18
Fire spread degree	NRO
Type of external / internal proﬁling	[M], [T1], [R], [F] / [T1], [M], [F]
External / internal corrosion resistance	C1, C2, C3 (C4 ÷ C5) / A1 (A2 ÷ A5)
Standard coatings	Poliester Interior [INT], Poliester Standard [RAL], HERCULIT [HC], MULTILAYER 40 [MLT]
Special coatings	PVDF, PUR, PVC (P), PVC (F) - FoodSafe
Accessories	fixing system, seals, flashings, rooflight

External profiling

Internal profiling

Types of material

POLIESTER Interior [INT]

POLIESTER Standard [RAL]

HERCULIT [HC]

MULTILAYER [MLT]

Available colours

Sheet metal coated with a 15 μm polyester layer with a smooth and glossy surface. Due to the low thickness of the organic coating, it is mainly intended for interior applications and building elements not directly exposed to weathering.

Available colours

Basic organic coating with a thickness of 25 μm. The surface is uniform, smooth – shiny or metallic. A material with a very wide range of applications. It is available in a wide range of colours described by means of a universal RAL chart.

Warranty period: 10 years *
* Detailed warranty conditions are specified in the warranty card.

Available colours

It is a coating developed in close cooperation with a leading manufacturer of varnishes for the best steel mills in Europe. Many years of studying existing coatings and monitoring customer needs, with particular emphasis on the needs of roofers, have allowed us to condense so many different advantages into one product. HERCULIT is a polyurethanecured polyester with a high resistance to mechanical damage and a thickness of 35 μm.

40-year warranty*
*Detailed warranty conditions are specified in the warranty card.

Available colours

35 μm thick polyester paint with Z275 zinc layer or ZM120 zinc-magnesium layer. It is characterised by its wood structure and adequate protection against corrosion and UV radiation. This combination allows outdoor use, especially where high weather resistance and high aesthetics are required.
